Needle Corrugator Belt
- Product Details
-
Product Description
Needle corrugator belts are made of high-grade polyester fiber & NOMEX, produced by advanced Needle punch technology to meet the high temperature and high strength requirements of corrugated cardboard production lines.
Product Features
★ High-temperature resistance
★ Aging resistance
★ Smooth surface
★ Stable size
★ 50-60 million linear meters service lifeProduct Parameters
Product
Needle Punched Corrugator Belt
Thickness
9±0.3 mm
Width range
1400 mm – 3200 mm
Heat-resistance
200℃, Teflon edge 230℃
Tensile strength
70 Mpa
Coefficient of friction
≥ 0.38µ
Weight
(5.5±0.3)kg/㎡
Air-permeability
4.7 m³/㎡min
Seam
Concealed joint /Clipper fasteners
Adjustable rate(weft)
0.8%/180℃
Adjustable rate(warp)
0.42%/180℃
Service life
50-60 million meters (or 14000 working hours)
Packaging
Air shipment: woven bag and wooden pallet
Sea shipment: solid wooden boxProduct Gallery
